CO2 Fire Extinguisher

Get a Price/Quote

MOQ : 10 Pieces

CO2 Fire Extinguisher Specification

Features
Non-corrosive, Residue Free, Easy Operation, No Conductivity Risk

Mounting Type
Wall Mounted

Control Type
Squeeze Grip Valve

Coverage Area
2.5 to 3.5 meters spray range

Working Temperature
-30C to +60C

Operating Pressure
50 Bar

Coating Type
Red Epoxy Powder Coated

Fire Class
Class B & C

Shape
Cylindrical

Technology
Stored Pressure

Connectivity Type
Manual

Installation Type
Portable, Wall Mounted

Fire Extinguisher Type
CO2 (Carbon Dioxide)

Usage
Fire Safety

Application
Fire

Max Flow Rate
2-3 kg/sec

Capacity
2 kg / 4.5 kg / 6.8 kg

Diameter
140 mm (approximate standard unit size)

Pressure
50 Bar at 27C

Safety Seal
Tamper Proof

Discharge Time
8-18 seconds depending on capacity

Standards Compliance
BIS, CE Certified

ISI Certification
ISI Marked (as per IS 15683)

Nozzle Type
Horn Type

Discharge Mechanism
Controlled Discharge Nozzle

Cylinder Material
Seamless Manganese Steel

Weight (full)
Up to 10 kg depending on model

Test Pressure
250 Bar

Life Expectancy
5 Years (cylinder), Refillable

CO2 Fire Extinguisher Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Main Domestic Market
All India

About CO2 Fire Extinguisher

We are the trusted supplier of West Bengal, India, providing exclusive assortment of Commercial Fire Extinguisher. The offered fire extinguisher is widely used due to its hassle-free functionality, simple design, no malfunction possible and longer service life. This fire extinguisher is manufactured by using quality proven materials and with the help of the cutting-edge technology at our vendors premises. The offered Commercial Fire Extinguisher is used to extinguish small fires in case of emergency.

Features:

Optimum performance
Easy to use
User friendly operation

Technical Specification :

Description	BIS Spec.	Discharge Time (Sec.)	Jet Length (Mtrs.)	Test Pressure kgf/Cm2
ABC - 1kg. ABC - 2kg. ABC - 5kg. ABC - 10kg	13849 13849 13849 13849	8 - 10 8 - 10 20 - 25 20 - 30	3 - 4 3 - 4 4 - 5 5 - 6	30 30 30

Robust Construction and Certifications

Built from seamless manganese steel and coated with red epoxy powder, these extinguishers combine strength and corrosion resistance. Adhering to ISI, BIS, and CE standards, they guarantee dependable performance for fire safety and meet regulatory requirements in India.

Efficient Fire Suppression Technology

Utilizing stored pressure, the extinguisher delivers a powerful spray with a horn-type nozzle, covering areas up to 3.5 meters. Its non-conductive CO2 agent rapidly extinguishes Class B and C fires without leaving residue, protecting equipment and surfaces.

Convenient Operation and Maintenance

A squeeze grip valve ensures precise control, while the tamper-proof safety seal adds security. The cylindrical, wall-mounted design allows for easy installation, and its refillable feature enhances long-term usability, with a cylinder life expectancy of up to 5 years.

FAQs of CO2 Fire Extinguisher:

Q: How do I use a CO2 fire extinguisher with a horn-type nozzle?

A: To operate, remove the tamper-proof safety seal, aim the horn-type nozzle at the base of the fire, and squeeze the grip valve. Maintain steady control and discharge, keeping a safe distance of 2.5 to 3.5 meters until the fire is extinguished.

Q: What types of fires is this extinguisher suitable for?

A: This CO2 fire extinguisher is designed for Class B (flammable liquids) and Class C (electrical equipment) fires. The non-conductive and residue-free CO2 agent is ideal for protecting sensitive environments and electrical installations.

Q: When should the extinguisher be refilled or serviced?

A: It is recommended to have the extinguisher inspected and refilled after each use or annually, even if unused. Regular maintenance ensures the cylinder, valve, and safety mechanisms remain reliable throughout its 5-year life expectancy.

Q: Where can this CO2 fire extinguisher be installed?

A: This extinguisher is suited for portable use or wall mounting in offices, factories, server rooms, and other locations prone to Class B or C fires. Its cylindrical design and manageable weight allow for versatile installation options.

Q: What are the benefits of CO2 technology in fire extinguishing?

A: CO2 provides non-corrosive, residue-free extinguishing without conductor risk, making it safe for electrical fires. It acts quickly and efficiently, minimizing damage to property while maintaining ease of operation.

Q: What is the process for refilling this extinguisher in India?

A: Contact an authorized distributor, supplier, or trader with BIS and CE certified refilling facilities. The process involves thoroughly inspecting the cylinder, testing at 250 Bar pressure, and refilling with the appropriate CO2 capacity for continued safety compliance.
